How to Implement User Authentication in Flask with MySQLAlchemy

In this step-by-step guide, you'll learn how to build a secure user authentication system in Flask using MySQLAlchemy for database operations. We'll cover:

✅ User Registration (Signup)
✅ Login & Logout Functionality
✅ Password Hashing (Security Best Practices)
✅ Session Management
✅ Protected Routes (Dashboard)

This tutorial is perfect for developers who want to add authentication to their Flask applications while using MySQL as the database backend.

Why Flask + MySQLAlchemy for Authentication?

🔹 Flask is a lightweight Python framework ideal for web applications.
🔹 MySQLAlchemy provides an ORM (Object-Relational Mapping) for MySQL, making database operations easier.
🔹 Secure authentication is crucial for protecting user data.

By the end, you'll have a fully functional auth system that you can integrate into any Flask project!

Prerequisites

Before we start, make sure you have:

Python 3.6+ installed
MySQL Server installed and running
Basic knowledge of Flask, SQL, and Python

Step 1: Setting Up the Project

1. Create a Virtual Environment

python -m venv venv
source venv/bin/activate  # On Windows: venv\Scripts\activate

2. Install Required Packages

pip install flask flask-sqlalchemy flask-login flask-bcrypt flask-wtf

3. Project Structure

flask_auth_mysql/
│
├── app.py                # Main Flask application
├── models.py             # Database models (User)
├── forms.py              # Login & Registration forms
├── templates/            # HTML templates
│   ├── login.html        # Login page
│   ├── register.html     # Registration page
│   ├── dashboard.html    # Protected dashboard
│   └── layout.html       # Base template
└── requirements.txt      # Dependencies

Step 2: Configuring Flask & MySQLAlchemy

1. `app.py` – Flask Setup

from flask import Flask, render_template, redirect, url_for, flash, request
from flask_sqlalchemy import SQLAlchemy
from flask_login import LoginManager, UserMixin, login_user, logout_user, login_required, current_user
from flask_bcrypt import Bcrypt
from forms import RegistrationForm, LoginForm

app = Flask(__name__)

# Configuration
app.config['SECRET_KEY'] = 'your-secret-key-here'
app.config['SQLALCHEMY_DATABASE_URI'] = 'mysql://username:password@localhost/flask_auth_db'
app.config['SQLALCHEMY_TRACK_MODIFICATIONS'] = False

# Initialize extensions
db = SQLAlchemy(app)
bcrypt = Bcrypt(app)
login_manager = LoginManager(app)
login_manager.login_view = 'login'

# User Loader
@login_manager.user_loader
def load_user(user_id):
    return User.query.get(int(user_id))

# Import models after db initialization
from models import User

# Routes will be added here later

if __name__ == '__main__':
    app.run(debug=True)

2. `models.py` – User Model

from app import db, bcrypt
from flask_login import UserMixin

class User(db.Model, UserMixin):
    id = db.Column(db.Integer, primary_key=True)
    username = db.Column(db.String(50), unique=True, nullable=False)
    email = db.Column(db.String(100), unique=True, nullable=False)
    password = db.Column(db.String(60), nullable=False)

    def __repr__(self):
        return f"User('{self.username}', '{self.email}')"

3. `forms.py` – Login & Registration Forms

from flask_wtf import FlaskForm
from wtforms import StringField, PasswordField, SubmitField
from wtforms.validators import DataRequired, Length, Email, EqualTo

class RegistrationForm(FlaskForm):
    username = StringField('Username', validators=[DataRequired(), Length(min=2, max=20)])
    email = StringField('Email', validators=[DataRequired(), Email()])
    password = PasswordField('Password', validators=[DataRequired()])
    confirm_password = PasswordField('Confirm Password', validators=[DataRequired(), EqualTo('password')])
    submit = SubmitField('Sign Up')

class LoginForm(FlaskForm):
    email = StringField('Email', validators=[DataRequired(), Email()])
    password = PasswordField('Password', validators=[DataRequired()])
    submit = SubmitField('Login')

Step 3: Creating the Database

1. Create MySQL Database

CREATE DATABASE flask_auth_db;

2. Initialize Database in Flask

Run in Python shell:

from app import app, db
with app.app_context():
    db.create_all()

Step 4: Implementing Authentication Routes

1. Registration Route (`app.py`)

@app.route('/register', methods=['GET', 'POST'])
def register():
    if current_user.is_authenticated:
        return redirect(url_for('dashboard'))

    form = RegistrationForm()
    if form.validate_on_submit():
        hashed_password = bcrypt.generate_password_hash(form.password.data).decode('utf-8')
        user = User(username=form.username.data, email=form.email.data, password=hashed_password)
        db.session.add(user)
        db.session.commit()
        flash('Account created! You can now log in.', 'success')
        return redirect(url_for('login'))

    return render_template('register.html', form=form)

2. Login Route (`app.py`)

@app.route('/login', methods=['GET', 'POST'])
def login():
    if current_user.is_authenticated:
        return redirect(url_for('dashboard'))

    form = LoginForm()
    if form.validate_on_submit():
        user = User.query.filter_by(email=form.email.data).first()
        if user and bcrypt.check_password_hash(user.password, form.password.data):
            login_user(user)
            next_page = request.args.get('next')
            return redirect(next_page) if next_page else redirect(url_for('dashboard'))
        else:
            flash('Login failed. Check email and password.', 'danger')

    return render_template('login.html', form=form)

3. Logout & Dashboard Routes (`app.py`)

@app.route('/dashboard')
@login_required
def dashboard():
    return render_template('dashboard.html', username=current_user.username)

@app.route('/logout')
def logout():
    logout_user()
    return redirect(url_for('login'))

Step 5: Creating HTML Templates

1. `templates/layout.html` (Base Template)

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Flask Auth with MySQL</title>
    <link href="https://cdn.jsdelivr.net/npm/bootstrap@5.1.3/dist/css/bootstrap.min.css" rel="stylesheet">
</head>
<body>
    <nav class="navbar navbar-expand-lg navbar-dark bg-dark">
        <div class="container">
            <a class="navbar-brand" href="/">Flask Auth</a>
            <div class="navbar-nav ms-auto">
                {% if current_user.is_authenticated %}
                    <a class="nav-link" href="{{ url_for('dashboard') }}">Dashboard</a>
                    <a class="nav-link" href="{{ url_for('logout') }}">Logout</a>
                {% else %}
                    <a class="nav-link" href="{{ url_for('login') }}">Login</a>
                    <a class="nav-link" href="{{ url_for('register') }}">Register</a>
                {% endif %}
            </div>
        </div>
    </nav>

    <div class="container mt-4">
        {% with messages = get_flashed_messages(with_categories=true) %}
            {% if messages %}
                {% for category, message in messages %}
                    <div class="alert alert-{{ category }}">
                        {{ message }}
                    </div>
                {% endfor %}
            {% endif %}
        {% endwith %}

        {% block content %}{% endblock %}
    </div>

    <script src="https://cdn.jsdelivr.net/npm/bootstrap@5.1.3/dist/js/bootstrap.bundle.min.js"></script>
</body>
</html>

2. `templates/register.html`

{% extends "layout.html" %}

{% block content %}
<div class="row justify-content-center">
    <div class="col-md-6">
        <h2 class="mb-4">Register</h2>
        <form method="POST" action="">
            {{ form.hidden_tag() }}
            <div class="form-group mb-3">
                {{ form.username.label(class="form-label") }}
                {{ form.username(class="form-control") }}
            </div>
            <div class="form-group mb-3">
                {{ form.email.label(class="form-label") }}
                {{ form.email(class="form-control") }}
            </div>
            <div class="form-group mb-3">
                {{ form.password.label(class="form-label") }}
                {{ form.password(class="form-control") }}
            </div>
            <div class="form-group mb-3">
                {{ form.confirm_password.label(class="form-label") }}
                {{ form.confirm_password(class="form-control") }}
            </div>
            <div class="form-group">
                {{ form.submit(class="btn btn-primary") }}
            </div>
        </form>
        <p class="mt-3">Already have an account? <a href="{{ url_for('login') }}">Login</a></p>
    </div>
</div>
{% endblock %}

3. `templates/login.html`

{% extends "layout.html" %}

{% block content %}
<div class="row justify-content-center">
    <div class="col-md-6">
        <h2 class="mb-4">Login</h2>
        <form method="POST" action="">
            {{ form.hidden_tag() }}
            <div class="form-group mb-3">
                {{ form.email.label(class="form-label") }}
                {{ form.email(class="form-control") }}
            </div>
            <div class="form-group mb-3">
                {{ form.password.label(class="form-label") }}
                {{ form.password(class="form-control") }}
            </div>
            <div class="form-group">
                {{ form.submit(class="btn btn-primary") }}
            </div>
        </form>
        <p class="mt-3">Don't have an account? <a href="{{ url_for('register') }}">Register</a></p>
    </div>
</div>
{% endblock %}

4. `templates/dashboard.html`

{% extends "layout.html" %}

{% block content %}
<div class="row justify-content-center">
    <div class="col-md-8">
        <h2>Welcome, {{ username }}!</h2>
        <p>This is your secure dashboard.</p>
    </div>
</div>
{% endblock %}

Step 6: Running the Application

Start the Flask development server:

python app.py

Visit:

Register: http://127.0.0.1:5000/register
Login: http://127.0.0.1:5000/login
Dashboard: http://127.0.0.1:5000/dashboard (Protected)

Conclusion

You’ve successfully built a Flask authentication system with MySQLAlchemy! 🎉

🔹 Users can register, log in, and log out.
🔹 Passwords are securely hashed.
🔹 Protected routes ensure only logged-in users access the dashboard.

Next Steps:

✅ Add email verification
✅ Implement password reset functionality
✅ Deploy to production (e.g., using Gunicorn + Nginx)
